5G/LTE/GNSS/WiFi loftnet, Omni 2x2 mimo – PR1ICA60
26 people are viewing this right now
12 products sold in last 13 hours
Selling fast! Over 8 people have this in their carts
- Estimated Delivery : Up to 2 business days
- Free Shipping : On all orders over 1,000 AED
Lýsing Loftnet með 5G/LTE, GNSS og Wifi til að setja router inn í. Meiri upplýsingar hér 5G ANTENNA Frequency Range 617 ~ 960, 1700 ~ 2700, 3300 ~ 4300 MHz Polarisation Vertical Radiation pattern type Omnidirectional Gain Max 4.5 dBi V.S.W.R < 2.50 Impedance 50 Ω Connector type and count 2x SMA male GNSS ANTENNA Frequency Range 1560 ~ 1610 MHz Polarisation RHCP Gain 28 dBi V.S.W.R < 2.00 Impedance 50 Ω Connector type and count 1x SMA male Current consumption 2.5 – 6.5 mA Supply voltage 2.5 – 6.5 VDC WI-FI ANTENNA Frequency Range 2400 ~ 2500, 4700 ~ 6000 MHz Polarisation Vertical Radiation pattern type Omnidirectional Gain Max 7.5 dBi V.S.W.R < 2.00 Impedance 50 Ω Connector type and count 2x RP-SMA male MECHANICAL/ENVIRONMENTAL Cable 6x RG316, 1x RG174 Operating Temperature -40 °C to 75 °C Mounting Method Wall, ceiling, mast IP rating IP67 Weight 1500 g RoHS compliant ✓
