Þráðlaus aðgangspunktur - UniFi U6-IW

Lýsing Wall-mounted WiFi 6 access point with a 300-client capacity and a built-in Gigabit, PoE switch. The UniFi6 In-Wall (U6 IW) is a dual-band, wall-mounted access point with (4) GbE RJ45 ports that brings plug-and-play WiFi 6 to your home or office. One of the U6 IW’s ports also supports PoE output so you can connect and power an Ethernet device. With its 2.4 and 5 GHz WiFi 6 bands, the U6 IW offers an aggregate, over-the-air throughput rate of 5.3 Gbps, which can support over 300 clients. The U6 IW is also Bluetooth-compatible so it can be set up in minutes and managed from anywhere via the UniFi Network web application or mobile app. Features: High-efficiency, four-stream WiFi 6 technology 5 GHz WiFi 6 band (4×4 MU-MIMO and OFDMA) 2.4 GHz WiFi 6 band (2×2 MU-MIMO) (4) GbE RJ45 ports, including one that supports PoE output 300 client capacity Simple, Bluetooth-powered setup via the UniFi Network web application or mobile app Managed with UniFi Network application: Version 6.4.52 and later Mechanical Dimensions 139.66 x 96 x 31.19 mm (5.5 x 3.78 x 1.28″) Weight 460 g (1.01 lb) Enclosure materials Plastic, aluminum Mount material Aluminum Hardware Processor specs Dual-Core® Cortex® A53 at 1 GHz Memory information 1 GB Management interfaces Ethernet Bluetooth Networking interfaces (1) Data-in: 1GbE RJ45 port (4) Data-out: 1GbE RJ45 ports PoE interfaces (1) PoE in (PoE output not used) (1) PoE out (requires a PoE switch) Button Factory reset LED* White/blue *Due to chip supply shortages, the U6 AP’s LED has been limited to only white and blue color modes. Power method PoE Power supply UniFi PoE switch 48V, 0.5A PoE adapter (optional) Max. power consumption Excluding PoE output: 13.5W Max PoE wattage per port by PSE 15.4W* *Requires a PoE switch Voltage range PoE mode 44 to 57VDC Max. TX power 2.4 GHz 5 GHz 22 dBm 26 dBm MIMO 2.4 GHz 5 GHz 2 x 2 (UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) Throughput rate 2.4 GHz 5 GHz 573.5 Mbps 4.8 Gbps Antenna gain 2.4 GHz 5 GHz 5 dBi 5.9 dBi Operating temperature -30 to 60° C (-22 to 140° F) Operating humidity 5 – 95% noncondensing Certifications CE, FCC, IC Software WiFi standards 802.11a/b/g WiFi 4/WiFi 5/WiFi 6 Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) BSSID 8 per radio VLAN 802.1Q Advanced QoS Per-user rate limiting Guest traffic isolation Supported Concurrent clients 300 Zero-wait DFS Yes Supported Data Rates 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n (WiFi 4) 6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40) 802.11ac (WiFi 5) 6.5 Mbps to 3.4 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)
